Recoil RL680.4 680 Watts Full Range Class-D 4 Channel Amplifier

Recoil RL680.4 680 Watts Full Range Class-D 4 Channel Amplifier

£99.99 GBP
£99.99 GBP
Sale Sold out
Taxes included. Shipping calculated at checkout.

The Recoil RL680.4 is a 680 watt full range Class-D 4-channel amplifier. At 14.4V it delivers 170W x 4 at 2 ohm, 95W x 4 at 4 ohm, or 250W x 2 bridged at 4 ohm.

Key features

  • Full range Class-D amplifier with 4 channels
  • 4-way protection circuit: thermal, voltage, speaker and DC
  • Crossover LPF and HPF, each 30Hz-300Hz
  • Operating voltage 9V-16V

Specifications

Protection circuit 4-way: thermal, voltage, speaker, DC
Power at 1 ohm (14.4V) N/A
Power at 2 ohm (14.4V) 170W x 4
Power at 4 ohm (14.4V) 95W x 4
Bridged power at 4 ohm (14.4V) 250W x 2
Bridged power at 2 ohm (14.4V) N/A
Operating voltage 9V-16V
Idling current (power on) 750mA
Frequency response 20Hz-35kHz
Signal to noise ratio (SNR) 89.9dB
THD+N (at 1W) 0.16%
Input sensitivity (low level) 220mV-12V
Input sensitivity (high level) N/A
Bass boost N/A
Subsonic filter N/A
Crossover LPF 30Hz-300Hz
Crossover HPF 30Hz-300Hz
Bass remote N/A
Clip indication 1%
Fuse rating 35A
Dimensions 3.97″ x 4.92″ x 2″ (108mm x 125mm x 51mm)
