Recoil PLOC2PRO Line Output Converter - 2-CH IN & 4-CH OUT WITH BASS BOOST

The Recoil PLOC2PRO is a line output converter with bass boost, with 2 channels in and 4 channels out. It handles up to 40 V of speaker-level input and gives a 9.5 V RCA output.

Key features

• Built for installers working with high-output OEM source units that demand more than a basic line output converter can handle
• Bridges factory head units and aftermarket amplifiers without signal compromise
• High-voltage input handling: accepts up to 40 V of speaker-level signal, compatible with high-powered factory amplified systems
• 4-channel output configuration: 2 channels of full-range RCA output plus 2 dedicated bass RCA outputs for flexible amplifier integration
• Bass boost and compensation: onboard bass processing with a remote level controller and voltage display for precise low-frequency tuning
• Clip indicator: provides real-time feedback during setup to prevent distortion at the amplifier input
• Flexible turn-on modes: selectable Remote, DC and Audio-sensing trigger options to suit any installation
• Configurable load and ground isolation: onboard load resistor selection and ground isolation modes address noise in complex OEM environments
• The dedicated bass output channels and onboard bass boost make it especially suited for systems where a separate subwoofer amplifier is in the chain
