WOOFER Nominal power 40 W Maximum power 80 W Sensitivity 89.5 dB Nom. impedance 4 Ω Cone Polyglass Surround Butyl DC resistance 3.5 Ω VC diameter 25 mm1" Former Kapton Layers 2 Wire Copper Net weight 400g 0.88lb Frequency response 80-23000 Hz Crossover 6 dB/Oct @4 kHz
TWEETER Nominal power 20 W Maximum power 80 W Sensitivity 90 dB Nom. impedance 4 Ω Cone Aluminium Magnesium Surround Poron DC resistance 3.6 Ω VC diameter 20mm 1" Former Kapton Layers 2 Wire Alu Net weight 60g 0.13lb
