DLS PE1.1000 1 Channel Mono Amplifier

DLS PE1.1000 1 Channel Mono Amplifier

£234.95 GBP
£234.95 GBP
Sale Sold out
Taxes included. Shipping calculated at checkout.

The DLS PE1.1000 is a 1 channel (mono) Class D amplifier for subwoofer systems. It delivers 1 x 450 W RMS at 4 ohm, 1 x 750 W at 2 ohm and 1 x 1000 W at 1 ohm.

It is part of the DLS Performance Evolution amplifier range, designed with sound quality, control and usability in focus. It aims for a warm, natural sound with stable power delivery and predictable behaviour in real-world systems, keeping low-frequency performance tight, musical and well integrated with the rest of the system.

Key features

  • Mono amplifier designed to drive subwoofers with control and precision
  • Tuned for natural playback: clear detail without becoming sharp, and dynamics that are present without sounding aggressive
  • Supports both low-level and high-level inputs
  • High-level input with Smart Load Circuitry and Auto Turn On for smooth integration with most factory systems
  • EMI-optimised circuit boards help reduce interference and preserve signal integrity
  • Adjustable low-pass filter (40 - 250 Hz) and subsonic filter (15 - 40 Hz)
  • Bass EQ at 45 Hz: 0 to +12 dB

Specifications

Channels Mono (1)
Amplifier class D
Power RMS (1 ohm) 1 x 1000 W
Power RMS (2 ohm) 1 x 750 W
Power RMS (4 ohm) 1 x 450 W
Frequency response 15 Hz - 250 Hz
Signal-to-noise ratio (A-weighted) >95 dB
THD at 4 ohm <0.1%
Low-pass filter 40 - 250 Hz (adjustable)
Subsonic filter 15 - 40 Hz (adjustable)
Bass EQ at 45 Hz 0 to +12 dB
High-level input with Auto Turn On Yes
High-level input with Smart Load Circuitry Yes
Power consumption, idle 0.9 A
Power consumption, max 116 A
Recommended fuse rating 125 A
Dimensions (H x W x D) 52.5 x 125 x 274 mm
Dimensions (W x D x H), as listed in the spec table 125 x 52.5 x 274
Weight 2.0 kg
